Environment Friendly Sealing and
Heat Insulation Solutions

MECHANICAL GLAND PACKINGS - OIL & SOLVENTS ACIDS ALKALIES CHEMICALS

Style Temperature Service Recommendation
23 -250oC to +300oC A DUPLEX plaited flexible combination packing having super grade fluoropolymer intimately treated with graphite to enhance lubricity and heat dissipation. This packing is self lubricating, mechanically strong & widely used in chemicals, petrochemicals, power plants, paper, pulp and food industries. Pressure 350 bar, pH 0 - 14.
172 -200oC to +280oC This is a cross braided combination packing having pure PTFE fibre with special high pressure resistant fibre filament yarn incorporated in it. This packing is most suitable to all fluids and corrosive chemicals. It has exceptionally good dimensional stability, creep resistance and is non toxic. Recommended for dairies, food and pharmaceutical industries, refineries & fertilizer plants. This Packing can withstand high pressure conditions in both rotary and reciprocating application. Pressure 500 bar, pH 2 - 12.
174 -200oC to +300oC An advanced technology packing. A special Duplex Braided construction made from synthetic aramid fibre, as strong as steel, and most flexible. Recommended for pumping granular and viscous fluids, even under high pressure condition. This packing is suitable for solvents, abrasive slurries fuel oil, high pressure dozing pumps alkalies and mild acids. A most effective packing for refinery, high pressure water injection system and as anti extrusion packing. Pressure 280 bar, pH 3 - 12.
176 -200oC to +300oC A high quality combination packing incorporated with graphite / PTFE fibres and special synthetic fibre to give additional reinforcement of sliding surface and heat dissipation property. It is most suited to centrifugal and reciprocating pumps with high pressure and sliding velocity for abrasive media. It resists hot water, oil, gases, greases liquid ammonia and carbamate solution under high pressure conditions. Pressure 500 bar, pH 3 - 12.
1003 -150oC to +300oC A combination packing inter braided with PTFE fibre, chemical resistant fibre and special compound to resist hot concentrated alkalies, organic and dilute acids . A very special low friction packing recommended to be used with high speed pumps, agitators shafts, oils, solvents, ammonia solution, concentrated caustics and Ketones. pH 2 - 12.
1094 -150oC to +300oC UNIVERSAL APPLICATION : High grade asbestos fibre yarn Duplex Braided packing impregnated with special PTFE suspensoid for severe caustic and other corrosive chemicals, solvent, oils and petroleum byproducts & oxygen service. pH 2 - 12.
1603 -150oC to +300oC A combination packing with specially selected fluoropolymer PTFE fibre and chemical resistant inorganic fibre yarn for resisting corrosive medium and concentrated acids. This construction improves the strength and chemical inertness of the packing. This combination packing is further treated with PTFE suspensoid. This packing can be used against acids, chlorine, in valves, pumps having chrome plated or stainless steel shafts. pH 2 - 14.
BELKA A braided form of packing manufactured in size 3, 4 & 5 mm. Sq. or round section in different styles of packing. It is specially designed for use in stuffing boxes, accurate small glands and valves.
