Product |
Style |
Temperature |
Service Recommendation |
CERAMIC |
|
|
Ceramic Yarn/Cloth have proved to be efficient and economical in High Temperature thermal insulation application in different industries including Petrochemicals, Glass, Steel, Metals, Chemicals Plants, Ship Building, Nuclear Power Plants, Extremely High Temperature working in lining industrial furnaces, process heaters, etc. |
|
SPECIAL |
500oC |
Special lagging rope is produced for specific high temperature insulation of packing for Dummy Bar in molten steel castings and such other purposes. |
|
SPECIAL |
500oC |
Special Yarn is produced in different grades to meet with specific requirements of higher temperature insulation. |
RUBBERISED CLOTH |
122 |
170oC |
Asbestos non metallic sheeting proofed with rubber, used for gasket joints, sealing handholes & manholes of boilers, covers of tanks and pressure vessels and applications against air, steam and water. Thickness 1.5 mm and above. |
|
122M |
170oC |
Similar to style 122 but with wire reinforcement. |
|
132 |
315oC |
Plain Weave Cloth 3.0 mm thick |
|
150 |
315oC |
Plain Weave Cloth 1.6 mm thick |
|
155 |
315oC |
Plain Weave Cloth 2.0 mm thick |
|
182 |
500oC |
1.6 mm cloth to DGS&D G/MISC/81/C Special Quality. |
|
186 |
500oC |
3.2 mm cloth to Indian Navy Spec INTC/23 Special Quality. |
RUBBERISED TAPE |
319 |
170oC |
Asbestos tape proofed with rubber for purposes of jointing for manhole and mudhole covers on boilers, tanks and pressure vessels. In coils of 30 meters with thickness upto 6 mm and width 12.5 mm onwards. |
|
319M |
170oC |
Similar to style 319 but with brass-wire reinforcement. |
|
AAA |
500oC |
Special Asbestos Cloth used for Diaphragm in Electrolytic cells and high temperature applications. |
ASBESTOS BRAIDED ROPE |
1000 |
350oC |
Asbestos dry plaited general steam and insulation packing for hot gases, oven, autoclaves, etc., conforming to IS Specification 4687 & DGS&D Specification. |
ASBESTOS YARN |
1056 |
315oC |
1.5 mm thick is twisted to sizes upto 50 mm Ø. For Dry Heat, caulking between rough or irregular surfaces, Blast Furnace connections, Coke Ovens, Gas Generator etc. |
|
1331 |
315oC |
Wire reinforced Asbestos Cloth 1.6 mm thick |
|
1900 |
650oC |
This Chrysotile, white dry, high purity, non-metallic, braided packing is used where severe high temperature conditions prevail. Best suited for expansion joints, door ovens, caulking of joints, exhaust pipe wrappings, ductings etc. |
ROPE |
7000 |
1250oC |
Ceramic rope in round/sqare section. |
YARN |
7012 |
1250oC |
Ceramic lagging rope having low density bulk fiber inside and braided on the outside using ceramic yarn. |
LAGGING ROPE |
7012 |
1250oC |
Low density fluffy asbestos fibre filled rope enclosed in a braided mesh cover. Used for insulation of steam pipe lines in power plants an industries in sizes 12 mm Ø to 51 mm Ø in standard coils of 30 meters. |
CLOTH |
7056 |
1250oC |
Ceramic yarn, nominal Ø 1.5mm & above. |
ASBESTOS |
7132 |
1250oC |
Ceramic cloth 3.2 mm thick, 1 m width. |
ASBESTOS CLOTH |
|
|
Asbestos cloth is used for thermal insulation in power plants, boiler mattresses, pipe lines, protective clothing and smothering fires. Available in plain or dust suppressed form. |
